X082 Air Compressor Permanent Magnetic Motor
Huizhou Cartee Electric & Machinery Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Material：Copper Iron
- Certification：ISO,TS16949, ISO9001
- Car Make：Carteeair
- OEM：Yes
Base Info
- Model NO.：X082
- Type：Air Suspension
- Specification：192L*80W*123MM
- Trademark：CARTEEAIR
- Origin：Huizhou, China
Description
12-Volt CompressorPSI LPM CFM AMP 0 36 1.27 5 10 24 0.85 6 20 23 0.81 7 30 21 0.74 8 40 19 0.67 8 50 17 0.60 8 60 16 0.57 9 70 15 0.53 9 80 13 0.46 9 90 12 0.42 9 100 11 0.39 9 110 10.5 0.37 9 120 10 0.35 * Supply Voltage: 13.8 Volts
CARTEEAIR offers the most comprehensive line of 12-volt and 24-volt air compressors for both the on-and off road markets available anywhere. Our quality engineered compressors and components are also used in the OEM segment, and have become the industry standard for automotive aftermarket applications worldwide.
INSTALLATION
Please read and follow the installation instructions carefully to avoid injury or damage to the compressor or your vehicle.
Each of our air compressors and parts have been carefully produced and packaged. Before you begin installation, please familiarize yourself with the manual.
Selecting a Mounting Location:
The selection of proper mounting location for your air compressor will help ensure a long and trouble free compressor service life. Please pay close attention to the following guidelines:
Do not mount compressor near areas where flammable liquids are stored.
CARTEEAIR offers the most comprehensive line of 12-volt and 24-volt air compressors for both the on-and off road markets available anywhere. Our quality engineered compressors and components are also used in the OEM segment, and have become the industry standard for automotive aftermarket applications worldwide.
INSTALLATION
Please read and follow the installation instructions carefully to avoid injury or damage to the compressor or your vehicle.
Each of our air compressors and parts have been carefully produced and packaged. Before you begin installation, please familiarize yourself with the manual.
Selecting a Mounting Location:
The selection of proper mounting location for your air compressor will help ensure a long and trouble free compressor service life. Please pay close attention to the following guidelines:
- Select a FLAT AND SECURE location where the compressor can be mounted.
- To maximize air compressor performance, locate compressor as CLOSE TO THE BATTERY as possible so that length of positive lead wire required is at a minimum.
- Choose mounting location that is as cool as possible and AWAY FROM HEAT SOURCES. The cooler the ambient temperature the less chance the compressor will overheat.
- This compressor is moisture & dust resistant, but NOT DUST OR WATER PROOF. Do not mount compressor in locations where the unit is likely to come in contact with water.
- If it is necessary to mount the air compressor further away from the battery, such as inside your vehicle or in the bed of your pickup, use a minimum 16 AWG positive lead wire for remote installation.
Do not mount compressor near areas where flammable liquids are stored.
