Auto, Motorcycle Parts & Accessories

Home > Product > Wheel Hub, Rim & Spoke

Factory One Piece/ 2pieces Forged Aluminum / Alloy Wheel / Rims for Cars (20*10, 20*11, 20*8.5, 20*9.0, 18*8.0, 18*8.5, 19*10.0, 19*8.5, 19*9.0, 20*10, 20*10.5)

QingDao TP Range Int'L Co., Ltd.
  • Material：Aluminum
  • Type：Rim
  • Drive Wheel：FWD
  • Wheel Hub Diameter：21-24"
  • Finishing：Polished
  • Wheel Accessories：Wheel

Base Info

  • Model NO.：20*10,20*11,20*8.5,20*9.0,18*8.0,18*8.5,19*10.0,19
  • Certification：ISO, VIA, CE, TUV, DOT, SMS
  • Transport Package：Pallet,Carton
  • Specification：22.5
  • Trademark：CHINA
  • Origin：China
  • HS Code：8716900000
  • Production Capacity：100000PCS,Year

Description

difference between steel and alloy wheelsPoints Forged Aluminum WheelSteel WheelAluminum wheel Advantages 1. Weight ~24KGS~45KGShalf lighter than steel one 2. MaterialHigh strength forging alloySteel PlateHigher strength 3. Manufacturing methodRotary forging Stamping , Rolling,Welding Forged from whole blank wheel, no weld-joint 4. Circularity Numerical Control Rolling roundness 5. Dynamic balanceUniform Density smooth-ride in high speed 6. Heat radiationHigh density no bubble ,high conductivity for heat less conductivity for heat expand service life of tyres by 26% 7. Impact resistance test Almost zero demage damage seriouslyhigher safety 8. Rigidityrigid deformable protect tyres from eccentric wear 9. Compression resistance 73000KGS deformed 5CM 13600KGS deformed 5CM High intensity , 5.37times than steel ones 10. AppearancePolished , Fine and Smooth Murky grey , roughPolished , Fine and Smooth 11. Cost3-4times  than steel one low cost 3-4times  than steel one 12. Recycle 95% recycled  95% recycled 13. Environment protect Save 22.9Kg of Co2 per KG of aluminum  Save 22.9Kg of Co2 per KG of aluminum

Forged Aluminum wheel Specifics
SIZEET(mm)P.C.D(mm)Stud(mm) C.B(mm)MAX LOADWEIGHT(kg)
20*100-40100-139.713/15/15R1257.1-108VIA770KG10.5-11.5
20*1130120*51572.6VIA770KG11.2
20*8.525120*51572.6VIA770KG9.7-10.0
20*9.020112*51566.6VIA770KG10.2
18*8.038120*51572.6VIA690KG8.5
18*8.544120*51572.6VIA690KG8.7
19*10.035120*51572.6VIA690KG10.4
19*8.535120*51572.6VIA690KG9.1-9.3
19*9.040120*51572.6VIA690KG9.6
20*1044112*51574.1VIA690KG10.6
20*10.545130*51571.62200LBS11.8
Factory One Piece/ 2pieces Forged Aluminum / Alloy Wheel / Rims for Cars (20*10, 20*11, 20*8.5, 20*9.0, 18*8.0, 18*8.5, 19*10.0, 19*8.5, 19*9.0, 20*10, 20*10.5)



5year-warranty  for all Forged aluminum wheel
