• Model NO.：3m9740bx130
• Update Method：by Hard Disk
• Color：Blue or Red
• Precision：High Precison
• Weight：3300Kgs
• Transport Package：Plywood Case
• Specification：CE SGS ISO9001
• Trademark：HOTON
• Origin：Shandong China
• HS Code：8458190000
• Production Capacity：20 PCS,Month

Basic Info.

Model NO. 3m9740bx130 Update Method by Hard Disk Color Blue or Red Precision High Precison Weight 3300Kgs Transport Package Plywood Case Specification CE SGS ISO9001 Trademark HOTON Origin Shandong China HS Code 8458190000 Production Capacity 20 PCS/Month

Product Description

It suits for grinding and milling all kinds of cylinder body and cover surface.

Structure characters:

1. The spindle adopts high precision bearing,the motor is fixed on the back of the machine,which guarantee the spindle prcision with high speed.
2. It adopts the plastic guide-way,running atable and flexible.
3. The feeding of work table adopts stepless adjusting,suits for processing all kinds of materials of work piece.



Model	3M9740B×130	3M9740B×150
Workbench dimension	1300×500mm	1500×500mm
Max.working length	1300mm	1500mm
Max.working width	350mm	350mm
Max.working height	800mm	800mm
Emery wheel disk moving travel	60mm	60mm
Workbench moving speed	40-900r/min	40-900r/min
Emery wheel disk diameter	360mm	360mm
The speed of revolution of main motor	1400/700(Frequency control of motor speed)r/min	1400/700(Frequency control of motor speed)r/min
Power of the main motor	1.5/2.4kw	1.5/2.4kw
Feed motor power	0.75kw	0.75kw
Cooling motor power	40w	40w
N.W	2.2T	2.2T

Contact Us:

Ashley Liu TENGZHOU HOTON MACHINERY CO.,LTD

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.
