High Quality Wheel Aligner (AA-WA518)
AA4C Automotive Co., Ltd.- Type：CCD Locator
- Certification：CE
- Communication Mode：Wire Communication
- Structure：Electronic
- Standard：Standard
- Condition：New
Base Info
- Model NO.：AA-WB718
- Specification：CE
- Trademark：AA4C
- Origin：China
- Production Capacity：100units,Month
Description
Basic Info.
Model NO. AA-WB718 Specification CE Trademark AA4C Origin China Production Capacity 100units/MonthProduct Description
1. Independent knowledge property right, and abundant vehicle data source, which provide long benefit for the customer;2. Advanced 8-beam CCD image measurement system, which with high precision, strong resistance for environmental interference, and good repetition;
3. All digital sensor, LED electronic gradienter structure, which keep step with numeral era;
4. Strengthen bluetooth communication, which is stable and credible, and also long distance communication;
5. Special sensor with LCD screen and sensitive to light, which shows measurement results directly on the screen, and with the function of all-day working even if without power or lighting;
6. Turning measurement could adopt 8 degree, 20 degree no turntable measurement;
7. Unique appearance design, vogue structure, especially for super-low chassis vehicle;
8.3D course navigation, equipped with voice indication and video direction;
9. Advanced closed self-diagnose system could discover and indicate system error and solved ways, which make clients safe to use;
10. Fashionable sensor design, equipped with fashionable small cabinet and 19" LCD display;
11. Install < Ver4.0> software on the Windows;
| Function Feature/ Product Name | AA-WA518 | AA-WA528 | AA-WA618 | AA-WB628 | AA-WB718 | AA-WB777 | AA-WB818 |
| 8-beam CCD | yes | yes | yes | yes | yes | yes | yes |
| Communication | radio | radio | radio | bluetooth | bluetooth | bluetooth | bluetooth |
| LCD Screen for Sensor | no | no | yes | yes | yes | yes | yes |
| Measurement When Power is off | no | no | yes | yes | yes | yes | yes |
| Monitor | 17"Flat | 17"Flat | 17" LCD | 17" LCD | 19" LCD | 19"LCD | 19"LCD |
| Self-diagnose Function | no | no | yes | yes | yes | yes | yes |
| Lift Adjustment | no | no | yes | yes | yes | yes | yes |
| Run Adjustment | no | no | yes | yes | yes | yes | yes |
| Cartoon Display | 3D cartoon | 3D cartoon | 3D navigation | 3D navigation | 3D navigation | 3D navigation | 3D navigation |
| Voice Indication | yes | yes | yes | yes | yes | yes | yes |
| Software Version | Ver:2.0 | Ver:3.1 | Ver:3.1 | Ver:3.1 | Ver:4.0 | Ver:4.0 | Ver:4.0 |
| Self-diagnose Function | no | no | yes | yes | yes | yes | yes |
| Automatic Ruler | non-support | non-support | support | support | support | support | support |
| PDA or Multiple screen | non-support | non-support | support | support | support | support | support |
| Measurement | Precision | Measurement field |
| Toe | ± 0.06 ° | ±5° |
| Camber | ± 0.06 ° | ±10° |
| Caster | ± 0.08 ° | ±18° |
| King pin | ± 0.08 ° | ±18° |
| Steer angle | ± 0.5 ° | ±5° |
| Thrust angle | ± 0.06 ° | ±5° |
| Set-back | ± 0.06 ° | ±10° |
