• Model NO.：3MB9817
• Update Method：by Hard Disk
• Working Travel of Slide board：450
• Color：Blue or Red
• Precision：High Precison
• Motor：2.2KW
• Weight：1350Kgs
• Transport Package：Plywood Case
• Specification：CE SGS ISO9001
• Trademark：HOTON
• Origin：Shandong China
• HS Code：8458190000
• Production Capacity：20 PCS,Month

Basic Info.

Model NO. 3MB9817 Update Method by Hard Disk Working Travel of Slide board 450 Color Blue or Red Precision High Precison Motor 2.2KW Weight 1350Kgs Transport Package Plywood Case Specification CE SGS ISO9001 Trademark HOTON Origin Shandong China HS Code 8458190000 Production Capacity 20 PCS/Month

Product Description

VERTICAL BRAKE DRUM CUTTING LATHE MACHINE FEATURES:
This machine is applicable for boring, repairing, machining, producing brake drum, brake shoe, brake disc of vehicles & tractors, it is with features as below:
1. High rigidity. The thickness of chassis is 450mm, which is integrated with transmission system & stand, so the rigidity is strengthened.
2. Wide machining range. This model is with very big machining diameter among all the brake drum boring machines in china. The max. machining diameter is 660 mm, and the function of machining brake discs is also available besides machining brake drums & brake shoes.
3.Perfect operation system. The quick up/down & positive/negative feed increases the working efficiency and the integrated button station achieves convenient operating.
SPECIFICATIONS:

MAIN SPECIFICATIONS	T8370
Range of Processing Diameter	180-700
Rotating Speed of Workpiece	24 / 45 / 80
Working Travel of Slide board	450
Overall Dimensions	1040 x 900 x 1720
Packing Dimensions	1150 x 1000 x 1820
N.W/G.W	1200 / 1350
Motor Power	2.2

Contact Us:

Andy Wang  TENGZHOU HOTON MACHINERY CO.,LTD   MP:0086 13506328892 hotonmachinery.en.made-in-china.com

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.
