• Model NO.：LT-980s
• Condition：New
• Power Supply /Motor Power：110V,220V,380V 1.1,0.75kw
• Bead Breaker Force：2500kg
• Rim Clamping Range (External )：Thirteen to Tweenty-Four
• Rim Clamping Range (Internal )：Fifteen to Tweenty-Six
• Transport Package：Wooden Case
• Specification：CE, ISO
• Trademark：AMCO
• Origin：Shaanxi
• Production Capacity：20-30 Sets , Month

Basic Info.

Model NO. LT-980s Condition New Power Supply /Motor Power 110V/220V/380V 1.1/0.75kw Bead Breaker Force 2500kg Rim Clamping Range (External ) Thirteen to Tweenty-Four Rim Clamping Range (Internal ) Fifteen to Tweenty-Six Transport Package Wooden Case Specification CE, ISO Trademark AMCO Origin Shaanxi Production Capacity 20-30 Sets / Month

Product Description

Tilt Back Tyre Changer LT-980S

1. Suitable for 13-26 Stiff & wide flat tires.
2. With self-centering function.
3. Clamping system with stepping function.
4. Bead seating inflation jets are integrated in the clamping jaws insuring quick and safe inflation.
5. Tilting column and pneumatic locking system.
6. Air reserve tank
7. Robotic arm(Optional)

8.  Plastic protector special for mount/demount tool.
9.  Angles of mount/demount tool can be adjusted and calibrated.
10. Polymer mount/demount tool of high quality prevent damage to the rim.
11. Optional adapter for motorcycle.

TECHNICAL DATA

Power supply /Motor power	110V/220V/380V  1.1/0.75KW
Air supply	0.8-1.2MPa
Rim clamping range (External )	13-24
Rim clamping range (internal )	15-26
Bead breaker force	2500kg
Max Wheel diameter	1100mm
Max Wheel width	15
Noise	<70dB
NW/GW	397kg/452kg

                                      Packing size;1200×1100×1650(mm)
