Roller Bearing 1301 Self-Aligning Ball Bearing for Motor Bearing
Shandong TFN Bearing Industry Co., Ltd.- Type：Engine Bearing
- Material：Stainless Steel, Bearing Steel
- Tolerance：P5
- Certification：ISO9001
- Clearance：C0
- ABS：Without ABS
Base Info
- Model NO.：1301
- Brand：Tfn
- Car Make：BMW
- Aligning：Aligning Bearing
- Separated：Unseparated
- Rows Number：Double
- Load Direction：Radial Bearing
- Contact Angle：0
- Product Name：Roller Bearing 1301 Self-Aligning Ball Bearing
- Size：12X37X12mm
- Weight：0.42kg
- Basic Dynamic Load Rating：9.36kn
- Basic Static Load Rating：2.16kn
- Fatigue Load Limit：0.12kn
- Reference Speed：40000r,Min
- Limiting Speed：28000r,Min
- Calculation Factor：0.04
- Vibration：Zv1, Zv2, Zv3, or as Requested
- Transport Package：Single Box Packaging,OEM
- Specification：12X37X12mm
- Trademark：TFN,OEM
- Origin：China
- HS Code：8482101000
- Production Capacity：10000,Month
Description
Quality Control Process 1.Assembly 2.Windage test2.Windage test 3.Cleaning 4.Rotary test 5.Greasing and gland 6.Noise inspection 7.Appearance inspection 8.Rust prevention 9.Product packaging Application low noise machine,automobile,motorcycle,and the general machinery and etc.
Limiting speeds(rpm)Mass(Kg) d D B rs min Cr Cor Grease Oil (Approx.) 13 Series 1300 10 35 11 0.6 7.25 1.62 18,000 21,000 0.058 1301 12 37 12 1 9.45 2.16 16,000 18,000 0.066 1302 15 42 13 1 9.55 2.3 13,000 16,000 0.092 1303 17 47 14 1 12.5 3.2 12,000 14,000 0.128 1304 20 52 15 1.1 12.4 3.35 11,000 13,000 0.16 1305 25 62 17 1.1 18 5 9,100 11,000 0.255 1306 30 72 19 1.1 21.3 6.3 7,700 9,100 0.383 1307 35 80 21 1.5 25.1 7.85 6,800 8,000 0.5 1308 40 90 23 1.5 29.6 9.7 6,000 7,000 0.709 1309 45 100 25 1.5 38 12.7 5,400 6,300 0.953 1310 50 110 27 2 43.5 14.1 4,900 5,800 1.2 1311 55 120 29 2 51.5 17.9 4,500 5,200 1.58 1312 60 130 31 2.1 57 20.8 4,100 4,800 1.96 1313 65 140 33 2.1 62 22.9 3,800 4,500 2.42 1314 70 150 35 2.1 74.5 27.7 3,500 4,200 2.99 1315 75 160 37 2.1 79.5 30 3,300 3,900 3.55 1316 80 170 39 2.1 88.5 33 3,100 3,600 4.17 1317 85 180 41 3 97.5 38 2,900 3,400 4.96 1318 90 190 43 3 116 44.5 2,700 3,200 5.78 1319 95 200 45 3 132 51 2,600 3,000 6.69 1320 100 215 47 3 143 57.5 2,400 2,900 8.3 1321 105 225 49 3 156 64.5 2,300 2,700 10 1322 110 240 50 3 164 71.5 2,200 2,600 11.8 13K Series 1304K 20 52 15 1.1 12.4 3.35 11,000 13,000 0.158 1305K 25 62 17 1.1 18 5 9,100 11,000 0.251 1306K 30 72 19 1.1 21.3 6.3 7,700 9,100 0.377 1307K 35 80 21 1.5 25.1 7.85 6,800 8,000 0.492 1308K 40 90 23 1.5 29.6 9.7 6,000 7,000 0.698 1309K 45 100 25 1.5 38 12.7 5,400 6,300 0.938 1310K 50 110 27 2 43.5 14.1 4,900 5,800 1.18 1311K 55 120 29 2 51.5 17.9 4,500 5,200 1.56 1312K 60 130 31 2.1 57 20.8 4,100 4,800 1.93 1313K 65 140 33 2.1 62 22.9 3,800 4,500 2.38 1315K 75 160 37 2.1 79.5 30 3,300 3,900 3.5 1316K 80 170 39 2.1 88.5 33 3,100 3,600 4.11 1317K 85 180 41 3 97.5 38 2,900 3,400 4.89 1318K 90 190 43 3 116 44.5 2,700 3,200 5.69 1319K 95 200 45 3 132 51 2,600 3,000 6.59 1320K 100 215 47 3 143 57.5 2,400 2,900 8.19 1322K 110 240 50 3 164 71.5 2,200 2,600 11.7
deep groove ball bearing packaging
FAQ of deep groove ball bearing
Limiting speeds(rpm) deep groove ball bearing packagingFAQ of deep groove ball bearing
1.Q:Are you a factory or trading company?
A:SEMRI Bearing is specialized in manufacturing and exporting bearings.
SEMRI Bearing have own factory and warehouse.
2.Q:Can I get some samples and do you offer the sample free?
A:Yes, sure, SEMRI Bearing are honored to offer you samples.Can you buy a ticket ?3.Q:What is the payment?
A: 30% T/T In Advance, 70% T/T Against Copy Of B/L
B: 100% L/C At Sight
4.Q:What is the MOQ for bearing?
A: SEMRI Bearing MOQ is 1 pc.
5.Q:What kind of service you can offer?
A:Technology support;Installation guidance;OE
