12VDC Electric Compressor for Roof-Top Air Conditioner Compressor

Kepler(Putian)Import&Export Co., Ltd.
  • Classification：Electric Compressor
  • Job Classification：Electric Power
  • Transmission Power：Dynamoelectric
  • Cooling Method：Refrigerant
  • Cylinder Arrangement Mode：Side-by-Side
  • Cylinder Stage：Multi Stages

Base Info

  • Model NO.：KP-DC20124000-T
  • Pressure after Air Exhaust：>1000 Gauge Pressure
  • Displacement：20cc,Rev
  • Rotation Speed：1000-4000rpm
  • Rotary Compressor：Scroll Type
  • Input Voltage：12VDC
  • Working Voltage Range：9-16VDC
  • Max Cooling Capacity：2.5kw
  • Transport Package：Carton
  • Origin：China
  • HS Code：8414301300
  • Production Capacity：200000PCS,Year

Description

Basic Info.

Model NO. KP-DC20124000-T Pressure after Air Exhaust >1000 Gauge Pressure Displacement 20cc/Rev Rotation Speed 1000-4000rpm Rotary Compressor Scroll Type Input Voltage 12VDC Working Voltage Range 9-16VDC Max Cooling Capacity 2.5kw Transport Package Carton Origin China HS Code 8414301300 Production Capacity 200000PCS/Year

Product Description

KEPLER 20CC ELECTRIC COMPRESSOR

SPECIALLY DESIGNED FOR 12VDC AND 24VDC AIR CONDITONER SYSTEM

Basic Parament for kepler 12vdc electric compressor

Displacement:20cc/reve
Speed:1000-4000rpm
Max cooling capacity:2.5kw
Rated Power Consunmption:1.2KW
Max working current:120amp
Refrigerant:R134A
OIL:RL68H
Input Voltage:12vdc(9-16vdc)
speed regulation:0-5V/5-11V/PWM
Net Weight:6.3kgs
Suction Pressure:0.2-0.45Mpa
Discharge Pressure:<2.5Mpa
IP Grade:IP67
Soft Start:15s
Noise:<70dB


12VDC Electric Compressor for Roof-Top Air Conditioner Compressor
